Height: 1558 mm
Width: 1129 mm
Depth: 528 mm
Seasonal space heating efficiency: 123 %
Seasonal space heating efficiency (colder climate conditions): 100 %
Seasonal space heating efficiency (warmer climate conditions): 163 %
Heating capacity: 30 kW
Power input (Outside air 7 °C, Heating water temperature step 30/35 °C): 7.7 kW
COP (Outside air 7 °C, Heating water temperature step 30/35 °C): 3.91
Power input (Outside air 7 °C, Heating water temperature step 40/45 °C): 10.35 kW
COP (Outside air 7 °C, Heating water temperature step 40/45 °C): 2.9
Power input (Outside air 7 °C, Heating water temperature step 47/55 °C): 13.04 kW
COP (Outside air 7 °C, Heating water temperature step 47/55 °C): 2.3
Cooling capacity (Outside air 35 °C, Cooling water temperature step 23/18 °C): 31 kW
Power input (Outside air 35 °C, Cooling water temperature step 23/18 °C): 7.75 kW
EER (Outside air 35 °C, Cooling water temperature step 23/18 °C): 4.0
Cooling capacity (Outside air 35 °C, Cooling water temperature step 12/7 °C): 29.5 kW
Power input (Outside air 35 °C, Cooling water temperature step 12/7 °C): 11.57 kW
EER (Outside air 35°C, Cooling water temperature step 12/7°C): 2.55
Cooling mode temperature range (air side): -5 - +46 °C
Cooling mode temperature range (water side): 5 - 25 °C
Heating mode temperature range (air side): -25 - +35 °C
Heating mode temperature range (water side): 5 - 60 °C
Domestic hot water temperature range (air side): -25 - +43 °C
Annual energy consumption: 19316 kWh
Annual energy consumption (colder climate conditions): 29238 kWh
Annual energy consumption (warmer climate conditions): 9580 kWh
Minimum water flow (flow switch): 27 l/min
Refrigerant: R32
Refrigerant charge weight: 5 kg
Voltage, frequency: 380 - 415 V, 50 Hz
Nominal operating current: 22.8 A
Maximum operating current: 28.5 A
Maximum fuse current: 32 A
Wire cross-section: 0.75 mm2
Pump lift height: 12 m
Expansion tank capacity: 8 l
Water connection: R 5/4"
Safety valve: 3 bar
Internal water volume: 3.5 l
Noise level: 77 dB
Weight: 206 kg
