Main advantages:
-10 years Hungarian warranty
-IP66 rated housing suitable for outdoor use
-Max. 20 A input current per string, compatible with 182/210 mm wafer-based PV modules
-Wide 150-1000 V MPP voltage range with low start-up voltage - increased production in low light conditions
-Quick and easy installation with standard tools
-Interchangeable II. type SPD
-Built-in Type II surge protection device on both DC and AC sides
Key Features:
-Reliable
-Compliance with international quality and safety standards
-DC reverse polarity protection and AC sensitive residual current monitoring function ensure long-term operation, with high emphasis on the safety of people and equipment
-Built-in surge protection device (Type II) protects the inverter against lightning hazards
-IP66 rated dustproof housing ensures sustainable usability against most environmental influences
-High performance
-Up to 32 A nominal input current per MPPT unit, allowing the PV power plant to be assembled from a more suitable selection of high-power bifacial and large-area PV modules
-Wide MPPT voltage range due to 150% PV system oversizing provides optimal energy yield and greater flexibility for almost any application position
-Electromechanical design with optimized thermodynamics ensures high power density
-Easy to install
-Equipped with Phoenix Contact DC connectors for quick and easy installation with standard tools
-Plug and play wifi module (included) and 4G module (optional) allowing easy monitoring of up to five inverters
-Quick setup and easy commissioning with the smart, cloud-based SOLPLANET app, which allows you to practically monitor your PV system wherever you are
Parameters:
-MAX. NUMBER OF INPUTS 2
-MAX. GENERATOR POWER 4500 Wp
-PHASE 3
-WARRANTY 10 years
-INVERTER TYPE String
-COOLING Passive
-PROTECTION DEGREE IP66
-HEIGHT 435 mm
-MAX. OUTPUT CURRENT 4.8 A
-MPP TRACKER NUMBER 2
-WIDTH 503 mm
-DEPTH 183 mm
-WEIGHT 15 kg
-EUROPEAN EFFICIENCY (ΗEU) 97.9%
